Rotating Turnstile iAccess TM-PASS Access Control

iAccess TM-PASS

Rotating Turnstile

Prezzo: €0.00
TOR06TM19
Trustpilot
Quantity:

    What is the iAccess TM-PASS Barrier?

    iAccess TM-PASS is a single-lane half-height rotating turnstile that creates a non-climbable barrier designed to allow the passage of only one person at a time. It is particularly suitable for controlling access with standard flows and is used in all environments where strict and peripheral control is required.

    It has a strong structure entirely made of 304 stainless steel and a 3-sector stainless steel rotor connected to a movement system specifically designed to withstand very high mechanical stress.

    iAccess TM-PASS
    Request Information

    Installing the iAccess TM-PASS barrier

    iAccess TM-PASS

    Installing the iAccess TM-PASS barrier is simple and fast. By following the manual instructions, the turnstile can be installed in just a few simple steps.
    The turnstile works completely independently: it only needs to be powered at 220V.

    It is possible to customize the turnstile operation for entry/exit according to your needs, choosing from the different operating modes.

    Traffic light signaling

    • LED with green arrow: free passage without the need for an unlocking signal
    • LED with red cross: passage not allowed
    Request Information
    iAccess TM-PASS
    iAccess TM-PASS

    Where can iAccess TM-PASS be installed?

    iAccess TM-PASS

    It can be easily interfaced with any iAccess access control system to allow passage only to authorized people or through a dedicated remote command.
    Suitable for:

    • Events and meeting places
    • Trade fairs and town festivals
    • Large offices and institutions

    Key Specifications

    • Type: single-lane full-height motorized barrier
    • Power supply: 220VAC / 24VDC
    • Usage environment: small and medium-sized events, large offices and centers
    • Weight: 200 kg
    • Material: 304 stainless steel with variable thickness from 1.5 mm to 2.0 mm.
    • Dimensions: 1301x1570x1343 mm. (HxWxD) Tripod arm length: 600 mm. Arm diameter: from 32 mm to 38 mm.
    • Passage release: bidirectional electric
    • Central rotor: central rotor made entirely of 304 stainless steel
    • Traffic lights: LED traffic lights with green arrow signal and red cross
    • Cable routing: connection cable outlet from the base
    • Fixing: floor fixing with expansion screws
    • Electromagnet voltage: 24 Vdc
    • Operating temperature: from -20°C to +70°C
    • Transit speed: 20-35 people per minute
    • Power: 30W
    • Protection rating: IP55
    • Opening: motorized with adjustable timing

    Standard Equipment

    • iAccess TM-PASS turnstile
    Power Supply 220 V
    220VAC / 24VDC
    Operating environment
    International events, major shipping locations and government agencies
    Weight
    250 kg
    Materiale
    STAINLESS STEEL 304 with variable thickness from 1.5 mm to 2.0 mm.
    Dimensions
    Tripod arms length: 600 mm.Arm diameter: from 32 mm to 38 mm.
    Sbocco dei passaggi
    Two-way electric
    Rotore centrale
    Central rotor made entirely of 304 stainless steel
    Semafori
    LED traffic lights with green arrow and red cross
    Passaggio cavi
    Output of the connection cables from the base
    Fissaggio
    Fixing to the ground by means of expansion screws
    Tensione elettromagneti
    24 Vcc
    Temperatura di funzionamento
    From -20C° to +70C°
    Velocità di transito
    40-70 people for minute
    Tipology
    Full-height motorized barrier with single gate
    Power
    30W
    Degree of protection
    IP65
    Opening
    Motorized with settable time
